Description
Product Details
This unique seal has optically clear adhesive free windows; these windows can be imaged through, and also allow for gas exchange. The clear film is made of a porous material which allows for a uniform air and CO₂ exchange, whilst acting as a moisture barrier and preventing evaporation. The seal is coated with a strong adhesive (except for the optical windows) which has a high sealing integrity. This ensures a reliable seal and prevention of well-to-well contamination.
The gas permeable seal enables long term incubations without intervention, whilst allowing for imaging through the optically clear windows. This can reduce the risk of sample contamination, evaporation and can improve your experimental workflow. Use of this seal within plate readers can prevent moisture release into the sensitive equipment.
A number of plate reader manufacturers recommend the use of the our Moisture Barrier Seal 24, 96, 384. For all adhesive seals, the best sealing results are achieved using the hand held Adhesive Seal Roller (4ti-0502).
Key Features
Quality & Properties
- Pierceable
- Peelable
- Seal integrity range: -20°C to 80°C
- Gas permeability rate: 0.6m³/m²/day
- Moisture vapor transmission rate: 1g/m²/day
- Optically clear for imaging
- Gamma irradiated
- Free from RNase and DNase
Use
- Applications: plate readers, eukaryotic cell culture, bacterial cell culture, long-term incubation, live cell assays, confocal microscopy
Options
- Sheet format: 140 x 80mm (4ti-0516/24) and 137 x 80mm (4ti-0516/96 and 4ti-0516/384)
- Available with 24/96/384 adhesive free windows for use with 24/96/384 well plates
Ordering Information
Part Numbers
| Moisture Barrier Seal 24, 96, 384 Gas permeable adhesive film, optically clear, with adhesive free windows, peelable, pierceable, gamma irradiated; suitable for cell culture |
|
|---|---|
| 4ti-0516/24 | sheets with 24 adhesive free windows (137 x 80mm); 5 packs of 10 sheets |
| 4ti-0516/96 | sheets with 96 adhesive free windows (137 x 76mm); 5 packs of 10 sheets |
| 4ti-0516/384 | sheets with 384 adhesive free windows (137 x 76mm); 5 packs of 10 sheets |
